Used 2023 EUROTECH CMZ TA-20-YS-640 | CNC Lathes
Have one to sell?
ConditionUsed
1 available
Twin-spindle CNC turning center with Y-axis and live tooling, built for complex, high-volume part work. It has a 15-position N-55 turret, a sub-spindle with through-spindle coolant, high-pressure coolant, and a bar feed interface.
Key Specifications
Control: Fanuc 32iTB with 15" touch screen and iHMI, G-code type A, English language
Max swing over bed: 29.9"
Max swing over slides: 23.6"
Max turning diameter: 18.1"
Distance between spindle centers: 24.6"
X-axis travel: 12.2"
Z-axis travel: 25.2"
Y-axis travel: +2.76" / -1.97"
B-axis travel: 25.2"
Main spindle max speed: 3,500 RPM
Sub-spindle max speed: 4,500 RPM
Turning torque: 752 ft-lbs max
Spindle bearing: 7.87" OD / 5.12" ID
Spindle nose ID: 3.58"
Draw tube bore: 3.23"
Chuck: 10" / 12.4" diameter, 3.23" bore
Turret: N-55, 15 positions, 1" x 1" tool shank
Machine dimensions: 100.1" x 69.3" x 83.5"
Included Options and Accessories
Standard hydraulic cylinder in main spindle (Autoblok VNK 150-67)
Air blow over main spindle
Removable tool presetter
Side-exit chip conveyor for Z=640 bed
Machine status indicator light
Tool life management function
Tool load monitoring function
High-pressure coolant pumps: 87 psi (6 bar) and 218 psi (15 bar)
Coolant filter (250 µm) with scraper-type cleaning
Pneumatic, automatic, programmable parts catcher with conveyor
Unimag bar feed interface
Pneumatic parts ejector for sub-spindle, 3.9" adjustable stroke
Coolant through sub-spindle
Machine manuals available as PDF download (cloud.cmz.com)
Driven Tool Holders
TTL/10400/02 axial driven holder, ER32, internal coolant to 1,015 psi (70 bar), 12,000 RPM
TTL/10400/05 radial driven holder, ER32, 12,000 RPM
Wrenches for ER16 and ER32 ring nuts
Capacity
Max swing over bed: 29.9" (760 mm)
Max swing over slides: 23.6" (600 mm)
Max turning diameter: 18.1" (460 mm)
Max turning length: 25.2" (640 mm)
Distance between spindle faces: 25.6" (649 mm)
Travels
X-axis: 12.2" (310 mm)
Y-axis: +2.76" / −1.97" (+70 / −50 mm)
Z-axis: 25.2" (640 mm)
B-axis (sub-spindle): 25.2" (640 mm)
Rapid traverse X / Z / B: 1,181 ipm (30 m/min)
Rapid traverse Y: 591 ipm (15 m/min)
Main Spindle
Max speed: 4,000 RPM
Power: 29.5 / 20.1 HP (22 / 15 kW)
Torque: 270 / 211 ft-lb (366 / 286 Nm)
Spindle nose: ASA 6" A2
Spindle bore: 2.87" (73 mm)
Bar capacity: 2.60" (66 mm)
Chuck: 8.27" (210 mm)
Hydraulic cylinder: Autoblok VNK 150-67
Sub-Spindle
Max speed: 4,500 RPM
Power: 18.8 / 10.7 HP (14 / 8 kW)
Torque: 215 / 113 ft-lb (292 / 153 Nm)
Spindle bore: 2.40" (61 mm)
Bar capacity: 2.05" (52 mm)
Chuck: 6.89" (175 mm)
Turret
N-55, 15 positions, live tooling
Live tool max speed: 12,000 RPM
Tool shank: 1" x 1" (25 mm)
Machine Dimensions
100.1" L x 69.3" W x 83.5" H (2,542 x 1,760 x 2,120 mm)
Driven Tool Holders
TTL/10400/02 axial driven holder, ER32, internal coolant up to 1,015 psi (70 bar), 12,000 RPM
TTL/10400/05 radial driven holder, ER32, 12,000 RPM
Wrenches for ER16 (330.12.0634) and ER32 (330.12.0637) ring nuts
Air blow over main spindle
Removable tool presetter
Side-exit chip conveyor for Z=640 bed
Machine status indicator light
Tool life management function
Tool load monitoring function
High-pressure coolant pumps: 87 psi (6 bar) + 218 psi (15 bar)
250 µm coolant filter with scraper-type cleaning
Pneumatic, automatic, programmable parts catcher with conveyor
Pneumatic parts ejector for sub-spindle, 3.9" (100 mm) adjustable stroke
Coolant through sub-spindle
Unimag bar feed interface
Twin-spindle CNC turning center with Y-axis and live tooling, built for complex, high-volume part work. It has a 15-position N-55 turret, a sub-spindle with through-spindle coolant, high-pressure coolant, and a bar feed interface.
Key Specifications
Control: Fanuc 32iTB with 15" touch screen and iHMI, G-code type A, English language
Max swing over bed: 29.9"
Max swing over slides: 23.6"
Max turning diameter: 18.1"
Distance between spindle centers: 24.6"
X-axis travel: 12.2"
Z-axis travel: 25.2"
Y-axis travel: +2.76" / -1.97"
B-axis travel: 25.2"
Main spindle max speed: 3,500 RPM
Sub-spindle max speed: 4,500 RPM
Turning torque: 752 ft-lbs max
Spindle bearing: 7.87" OD / 5.12" ID
Spindle nose ID: 3.58"
Draw tube bore: 3.23"
Chuck: 10" / 12.4" diameter, 3.23" bore
Turret: N-55, 15 positions, 1" x 1" tool shank
Machine dimensions: 100.1" x 69.3" x 83.5"
Included Options and Accessories
Standard hydraulic cylinder in main spindle (Autoblok VNK 150-67)
Air blow over main spindle
Removable tool presetter
Side-exit chip conveyor for Z=640 bed
Machine status indicator light
Tool life management function
Tool load monitoring function
High-pressure coolant pumps: 87 psi (6 bar) and 218 psi (15 bar)
Coolant filter (250 µm) with scraper-type cleaning
Pneumatic, automatic, programmable parts catcher with conveyor
Unimag bar feed interface
Pneumatic parts ejector for sub-spindle, 3.9" adjustable stroke
Coolant through sub-spindle
Machine manuals available as PDF download (cloud.cmz.com)
Driven Tool Holders
TTL/10400/02 axial driven holder, ER32, internal coolant to 1,015 psi (70 bar), 12,000 RPM
TTL/10400/05 radial driven holder, ER32, 12,000 RPM
Wrenches for ER16 and ER32 ring nuts
Capacity
Max swing over bed: 29.9" (760 mm)
Max swing over slides: 23.6" (600 mm)
Max turning diameter: 18.1" (460 mm)
Max turning length: 25.2" (640 mm)
Distance between spindle faces: 25.6" (649 mm)
Travels
X-axis: 12.2" (310 mm)
Y-axis: +2.76" / −1.97" (+70 / −50 mm)
Z-axis: 25.2" (640 mm)
B-axis (sub-spindle): 25.2" (640 mm)
Rapid traverse X / Z / B: 1,181 ipm (30 m/min)
Rapid traverse Y: 591 ipm (15 m/min)
Main Spindle
Max speed: 4,000 RPM
Power: 29.5 / 20.1 HP (22 / 15 kW)
Torque: 270 / 211 ft-lb (366 / 286 Nm)
Spindle nose: ASA 6" A2
Spindle bore: 2.87" (73 mm)
Bar capacity: 2.60" (66 mm)
Chuck: 8.27" (210 mm)
Hydraulic cylinder: Autoblok VNK 150-67
Sub-Spindle
Max speed: 4,500 RPM
Power: 18.8 / 10.7 HP (14 / 8 kW)
Torque: 215 / 113 ft-lb (292 / 153 Nm)
Spindle bore: 2.40" (61 mm)
Bar capacity: 2.05" (52 mm)
Chuck: 6.89" (175 mm)
Turret
N-55, 15 positions, live tooling
Live tool max speed: 12,000 RPM
Tool shank: 1" x 1" (25 mm)
Machine Dimensions
100.1" L x 69.3" W x 83.5" H (2,542 x 1,760 x 2,120 mm)
Driven Tool Holders
TTL/10400/02 axial driven holder, ER32, internal coolant up to 1,015 psi (70 bar), 12,000 RPM
TTL/10400/05 radial driven holder, ER32, 12,000 RPM
Wrenches for ER16 (330.12.0634) and ER32 (330.12.0637) ring nuts
Air blow over main spindle
Removable tool presetter
Side-exit chip conveyor for Z=640 bed
Machine status indicator light
Tool life management function
Tool load monitoring function
High-pressure coolant pumps: 87 psi (6 bar) + 218 psi (15 bar)
250 µm coolant filter with scraper-type cleaning
Pneumatic, automatic, programmable parts catcher with conveyor
Pneumatic parts ejector for sub-spindle, 3.9" (100 mm) adjustable stroke
Coolant through sub-spindle
Unimag bar feed interface
